Product Details:

Title Detail
Capacity 50 Kg/hour to 4000 Kg/hour
Brand SUPER CRYO
Automatic Grade Automatic
Design Customized
Material Suitable Material of Construction to make Food Grade of Carbon Di-Oxide
Production Rate 50 Kg/hour to 4000 Kg/hour
Voltage 415/380 Volt AC/3PH/50 - 60 Hz

Carbon Di-Oxide Recovery Plant

The most economical method to produce High-Purity Carbon Di-Oxide

At present CO2 Recovery plants are the most economical method to produce high-purity food grade carbon dioxide for beverage and food industries provided CO2 -rude gas in sufficient quantity and quality is available.

SUPER CRYO, CO2 - recovery plants are mainly designed for washing, purification cum drying and liquefaction and Storage of CO2 gas received from fermentation processes in breweries and distilleries plant, Reaction process of Calcium Chloride plant and from dry ice production processes. The CO2 -recovery plants are for automatic operation and require a minimum cost of operation.

Features of "SUPER CRYO" Plant

  • Competitive Price
  • Low Utilities Consumption
  • Low Installation Area
  • Short Erection & Commissioning time (due to pre-piped and wired skids mounted plant)
  • High Quality and Well-Proven Equipment
  • High Efficiency
  • High Performance
  • Low Maintenance Cost

Carbon Di-Oxide Recovery From

  • Fermentation Processes in Breweries and Distilleries Plant
  • Industrial Process/Fuel Gases

Brief Process Description

All kind of source- Brewery & Distillery fermentation, natural wells or chemical process industry by-product. "SUPER CRYO" is able to design a customized solution or offer a standard CO2-Recovery Plant to meet and exceed any customer requirements. Based on the advanced purification process, SUPER CRYO's technology removes any kind of impurities in primary purification section and then compressed in CO2 Compressor, Deodorize & Drying, Liquefaction & Striping where odor, moisture and non-condensable impurities are reduced to levels acceptable to make a food grade CO2 (ISBT compliant).

This innovative technical solution enriches the plant recovery capacity up to 99.99 % purity of the delivered CO2.

Major List of Equipment

(A) CO2 Recovery plant (CO2 Gas Received from Brewery Fermentation)

  • Foam Trap
  • Low Pressure Gas Scrubber
  • CO2 - Balloon
  • CO2 - Compressor
  • CO2 - Pre-Cooler with Separator
  • CO2 - Deodorizer cum Drying Unit
  • CO2 - Stripper Tower cum Re-Boiler
  • CO2 - Liquefier with Refrigeration Unit
  • Liquid CO2- Storage Tank with Condensing Unit
  • Motor Control Panel with PLC.

(B) CO2 Recovery plant (CO2 Gas Received from Distillery Fermentation)

  • Foam Trap
  • CO2 Gas Blower
  • L.P. Gas Scrubber
  • Buffer Tank
  • CO2 - Compressor
  • H.P. Gas Scrubber with High Pressure Water Circulation Pump
  • CO2 - Deodorizer Tower
  • CO2 - Pre-Cooler with Separator
  • CO2 - Drying Unit
  • CO2 - Liquefier with Refrigeration Unit
  • CO2 - Stripper Tower cum Re-Boiler
  • Nox Removal Tower(If required)
  • Liquid CO2- Storage Tank with Condensing Unit
  • Motor Control Panel with PLC

(C) CO2 Recovery plant (CO2 Gas Received from CaCl2 Process Plant)

  • Low Pressure Caustic Soda Scrubber with Circulation Pump
  • Low Pressure Water Scrubber with Circulation Pump
  • CO2 - Balloon
  • CO2 - Gas Compressor
  • KMnO4 Purification Tower
  • CO2 - Pre-Cooler with Separator
  • CO2 - Deodorizer Tower
  • CO2 - Drying Unit
  • CO2 - Stripper Tower cum Re-Boiler
  • CO2 - Liquefier with Refrigeration Unit
  • Liquid CO2- Storage Tank with Condensing Unit
  • Motor Control Panel with PLC

Additional Information:

  • Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer)
  • Port of Dispatch: By Sea or By Road
  • Delivery Time: Within 16 - 18 Weeks from the date of your confirmed order along with requisite advance Payment.
  • Packaging Details: Sea Worthy Packing for Export Project/ Normal Packing for Indian Project
